Description
Features & Benefits
Typical Applications
|
WATER PUMP Type Heavy Duty 3 chamber positive displacement diaphragm pump, self priming, capable of being run dry Mode demand Liquid Temperature 140°F (60°C) Max. Priming Capabilities 6 feet (1.8 m) suction lift Max Pressure 70 PSI Inlet/Outlet Ports 1/2″ – 14 MNPT |
MOTOR Duty Cycle Continuous Leads 16 AWG, 4.5″ long with 2-Pin connector/Leads Voltage 12v/24v |
- Compact automatic demand water system pump
- Built-in pressure switch automatically starts and stops pump when faucet is opened and closed
- Capable of supplying multiple fixtures
- Self-priming so pump can be located in a location higher than the water tank
- Run-dry safe
- Built-in thermal protection
Model | Switch | GPM/LPM | PSI/BAR | Max Draw (A) |
Valves | Diaphragm | Ports | Voltage | Wire Connections |
SFDP1-022-070-34 | Demand | 2.2 / 8.3 | 70 / 4.8 | 7.5 | EPDM | Santoprene | 1/2″- 14 MNPT | 12V | 2-Pin/Leads |
SFDP2-022-070-34 | Demand | 2.2 / 8.3 | 70 / 4.8 | 4.0 | EPDM | Santoprene | 1/2″- 14 MNPT | 24V | 2-Pin/Leads |
